What is the Hardness of a Material?
Hardness is defined as the resistance to permanent deformation or scratch. In other words, it is the ability to maintain its shape when an object is subjected to force.
There are three types of hardness:
Vickers hardness test (HV) – this method uses a special diamond pyramid with a specified load applied for a specific time. The hardness number assigned to different materials depends on the load used and the time taken to achieve that load.
Rockwell C scale – this test determines the hardness of a material by measuring the depth of penetration of a diamond-tipped stylus into its surface.
Brinell hardness test (HB) – this method uses more than one load and applies it at different speeds. This allows the testing of materials with varying properties like elasticity and plasticity, which cannot be determined using Vickers or Rockwell scales
When choosing a material or cutting tool to produce CNC machining parts, hardness should be considered.
Standard Hardness Conversion Calculator for Metals (ASTM)
Metal Hardness Tests – Difference Between Rockwell and Brinell Hardness Test
While the Rockwell hardness test and Brinell hardness test are used to measure the hardness of metals, they are different methods.
The Rockwell test measures the depth of indentation left on a piece of steel when pressed into it with a special diamond point. The hardness number is then determined by measuring how deep this indentation is.
The Brinell hardness test also uses a diamond point to make an indentation in the tested metal. Still, instead of measuring the depth of this indentation, it simply measures its size.
Both methods have their advantages. The Rockwell test is more accurate than the Brinell test because it measures just one depth rather than two different sizes. However, it can only be used on flat samples and not cylindrical ones like those found in pipe or rods.
Brinell, Rockwell, and Vickers Hardness Conversion Chart/Table
Brinell Hardness Conversion Chart
The Brinell hardness test measures the ability of a material to resist indentation. It determines the hardness of metals and alloys by measuring the depth (in millimeters) to which a hardened steel ball sinks into the test specimen under a standard weight. The result is reported as a number on a scale calibrated in area units (square millimeters). This test is used primarily for non-ferrous metals, with some exceptions, such as cast iron and most steels.
Rockwell Hardness Conversion Table
The Rockwell hardness test measures the resistance of a material to permanent deformation by an indenter under controlled conditions. The resulting hardness value is a number on the Rockwell scale in BHN or HRC units.
Vickers Hardness Conversion Table
The Vickers hardness test measures the resistance of a material to permanent indentation by an indenter under controlled conditions. The resulting hardness value is a number on the Vickers scale in either HV or HRA units.
| Tensile strength RmN/mm2 | Vickers hardness HV | Brinell hardness HB | Rockwell hardness HRC |
|---|---|---|---|
| 250 | 80 | 76 | - |
| 270 | 85 | 80.7 | - |
| 285 | 90 | 85.2 | - |
| 305 | 95 | 90.2 | - |
| 320 | 100 | 95 | - |
| 335 | 105 | 99.8 | - |
| 350 | 110 | 105 | - |
| 370 | 115 | 109 | - |
| 380 | 120 | 114 | - |
| 400 | 125 | 119 | - |
| 415 | 130 | 124 | - |
| 430 | 135 | 128 | - |
| 450 | 140 | 133 | - |
| 465 | 145 | 138 | - |
| 480 | 150 | 143 | - |
| 490 | 155 | 147 | - |
| 510 | 160 | 152 | - |
| 530 | 165 | 156 | - |
| 545 | 170 | 162 | - |
| 560 | 175 | 166 | - |
| 575 | 180 | 171 | - |
| 595 | 185 | 176 | - |
| 610 | 190 | 181 | - |
| 625 | 195 | 185 | - |
| 640 | 200 | 190 | - |
| 660 | 205 | 195 | - |
| 675 | 210 | 199 | - |
| 690 | 215 | 204 | - |
| 705 | 220 | 209 | - |
| 720 | 225 | 214 | - |
| 740 | 230 | 219 | - |
| 755 | 235 | 223 | - |
| 770 | 240 | 228 | 20.3 |
| 785 | 245 | 233 | 21.3 |
| 800 | 250 | 238 | 22.2 |
| 820 | 255 | 242 | 23.1 |
| 835 | 260 | 247 | 24 |
| 850 | 265 | 252 | 24.8 |
| 865 | 270 | 257 | 25.6 |
| 880 | 275 | 261 | 26.4 |
| 900 | 280 | 266 | 27.1 |
| 915 | 285 | 271 | 27.8 |
| 930 | 290 | 276 | 28.5 |
| 950 | 295 | 280 | 29.2 |
| 965 | 300 | 285 | 29.8 |
| 995 | 310 | 295 | 31 |
| 1030 | 320 | 304 | 32.2 |
| 1060 | 330 | 314 | 33.3 |
| 1095 | 340 | 323 | 34.4 |
| 1125 | 350 | 333 | 35.5 |
| 1115 | 360 | 342 | 36.6 |
| 1190 | 370 | 352 | 37.7 |
| 1220 | 380 | 361 | 38.8 |
| 1255 | 390 | 371 | 39.8 |
| 1290 | 400 | 380 | 40.8 |
| 1320 | 410 | 390 | 41.8 |
| 1350 | 420 | 399 | 42.7 |
| 1385 | 430 | 409 | 43.6 |
| 1420 | 440 | 418 | 44.5 |
| 1455 | 450 | 428 | 45.3 |
| 1485 | 460 | 437 | 46.1 |
| 1520 | 470 | 447 | 46.9 |
| 1555 | 480 | -456 | 47.7 |
| 1595 | 490 | -466 | 48.4 |
| 1630 | 500 | -475 | 49.1 |
| 1665 | 510 | -485 | 49.8 |
| 1700 | 520 | -494 | 50.5 |
| 1740 | 530 | -504 | 51.1 |
| 1775 | 540 | -513 | 51.7 |
| 1810 | 550 | -523 | 52.3 |
| 1845 | 560 | -532 | 53 |
| 1880 | 570 | -542 | 53.6 |
| 1920 | 580 | -551 | 54.1 |
| 1955 | 590 | -561 | 54.7 |
| 1995 | 600 | -570 | 55.2 |
| 2030 | 610 | -580 | 55.7 |
| 2070 | 620 | -589 | 56.3 |
| 2105 | 630 | -599 | 56.8 |
| 2145 | 640 | -608 | 57.3 |
| 2180 | 650 | -618 | 57.8 |
| 660 | 58.3 | ||
| 670 | 58.8 | ||
| 680 | 59.2 | ||
| 690 | 59.7 | ||
| 700 | 60.1 | ||
| 720 | 61 | ||
| 740 | 61.8 | ||
| 760 | 62.5 | ||
| 780 | 63.3 | ||
| 800 | 64 | ||
| 820 | 64.7 | ||
| 840 | 65.3 | ||
| 860 | 65.9 | ||
| 880 | 66.4 | ||
| 900 | 67 | ||
| 920 | 67.5 | ||
| 940 | 68 |
Rockwell and Brinell tests are different in how they measure hardness.
Rockwell and Brinell tests are different in how they measure hardness.
The Rockwell hardness test is performed with a Rockwell Hardness Tester (RHT). It measures the resistance of a material to permanent indentation by a diamond pyramid point. The larger the value this method measures, the harder the material is.
Brinell hardness test is performed with a Brinell Hardness Tester (BHT). It measures the resistance of a material to permanent indentation by a hardened steel ball. The larger the value measured by this method, the harder the material is.
